10.1 inch 1280*800 TFT Display Module with Touch and HDMI Board

The LTK101FTBHT50-V0 model has an IPS viewing angle and a resolution of up to 1280*800, which can provide clear viewing. The size is 248.00*165.00*4.80(mm), and the effective area is 216.96*135.60(mm), which has ample display space. It is connected via an LVDS interface. The brightness is 250cd/m2. The operating temperature range is -0~+50℃, and the storage temperature range is -20~+60℃, which is suitable for smart industrial applications.

Inquire Now

BackPrevious

Product Details

Part Number.	LTK101FTBHT50-V0
Resolution	1280*800
Display Mode	IPS
LCM A.A (mm)	216.96*135.60
LCM O.D (mm)	229.26149.082.60
LCM Luminance	300
Signal Input	LVDS
Signal Output	HDMI
PCB Outline	85.054.014.0
Operating Temp	-0~+50℃
Storage Temp	-20~+60℃
Power	12V/3A
Touch Screen	CTP
TPM V.A (mm)	215.70*134.40
TPM O.D (mm)	248.00165.004.80
TPM Luminance	250
