10.1 inch 1920*1200 TFT LCD Module with high brightless 1000nits

LTK101WUBLM20-V0 is a color active matrix TFT LCM using amorphous silicon TFT‘s (Thin Film Transistors) as an active switching devices. This module has a 10.1 inch diagonally measured active area with WUXGA resolutions (1920 horizontal by 1200 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 16.7M colors.

Inquire Now

BackPrevious Next

Product Details

Size(inch)	10.1
Mode	LTK101WUBLM20-V0
Display Mode	IPS
Resolution	1920*1200
Interface	LVDS
Brightness	1000 cd/㎡
Display Colors	16.7M(8bit )
Active Area(mm)	216.81×135.50
Outline Dimension(mm)	229.46×149.10×4.40
TFT Driver IC	TBD
Operating Temp	-20~+70℃
Storage Temp	-30~+80℃
