10.1 inch 1024*600 IPS Rugged Display for Military & Defense

This LTK101FTNLM54-V0 IPS LCD module features a high-resolution display of 1024*600 pixels, operates via an LVDS interface, and has a brightness of 850cd/m². The active area is 222.72*125.28mm, and the overall size is 235*143*5.12 mm. It can operate and store reliably in a temperature range of -30℃ to +80℃. It is ideally suited for smart industrial environments, providing clear, high-quality visuals and reliable performance under a variety of conditions.


  • Product Details

Part Number
LTK101FTNLM54-V0
Display Mode
IPS
Resolution
1024*600
Interface LVDS
Display Mode
Normally Black
Viewing Direction
ALL
Luminance (cd/m²)
850
Active Area (mm)
222.72*125.28
Outline Dimension (mm)
235*143*5.12
perating Temp
-30~+80℃
Storage Temp
-30~+80℃
