17.3 Inch 1366*512 Resolution TFT LCD Display with 1000nits

Welcome to Leadtek!Today we are pleased to introduce our 17.3-inch IPS TFT LCD,with a high resolution of 1366 x RGB x 512 and a brightness of 1000 cd/m², it delivers vivid visuals and excellent clarity, even in bright environments. The IPS panel ensures an ultra-wide viewing angle, while the "Normally Black" mode enhances contrast for deeper blacks and richer colors.

Featuring an LVDS interface and a compact design (435.80 x 178.60 x 13.20 mm), this display is easy to integrate into modern smart home systems. Built to withstand a range of conditions,perfect for creating engaging and dynamic corridor displays in any smart home.

Part Number.：LTK173FTBBM11-V0

LCD Size：TFT"17.3

Panel Type：IPS
Display Resolution：1366 x RGB x 512
LCM Interface：LVDS
Luminance (cd/m²)：1000
Display Mode：Normally Black
Number of Colors：16.7
Viewing Direction：ALL
LCM Module size(mm)：435.80*178.60*13.20

Panel Active Area(mm)：409.80*153.60
Operating Temp：0~+50℃
Storage Temp：-20~+60℃

If you want to know more about this product, please leave a message or contact us.
