3.9 Inch 480*128 UART TFT LCD Module With touch screen
This LTK039MNBUT11-V0 IPS LCD module has a resolution of 480*128, a brightness of 420cd/m², an effective display area of 95.04*25.34mm, an overall size of 113.20*40.85*4.15mm, and is equipped with a capacitive touch screen (CTP). It can operate reliably in a temperature range of -20℃ to +70℃ and is designed for smart home applications, ensuring clear, delicate visual effects and stable performance in various home environments.
- Product Details
|
Part Number |
LTK039MNBUT11-V0 |
|
Resolution |
480*128 |
|
Display Mode |
IPS |
|
LCM A.A (mm) |
95.04*25.34 |
|
LCM O.D (mm) |
103.20*34.85*2.50 |
|
LCM Luminance |
500 |
|
Signal Input |
RGB |
|
Signal Output |
UART TTL&232&485 |
|
PCB Outline |
56.00*66.00 |
|
Operating Temp |
-20~+70℃ |
|
Storage Temp |
-30~+80℃ |
|
Power |
5V/2A |
|
Touch Screen |
CTP |
|
TPM V.A (mm) |
95.64*25.94 |
|
TPM O.D (mm) |
113.20*40.85*4.15 |
|
TPM Luminance |
420 |
|
Flash |
1GB (support 128Mbit~2*1GB) |
