3.97 Inch 480*800 Transflective Display with CTP Touch Screen

Today we are going to introduce a new product 3.97-inch LCD module. Featuring a Transflective display that combines transmissive and reflective technologies for optimal visibility in both bright sunlight and low-light conditions. With a resolution of 480 x RGB x 800, 16.7M colors, and delivers sharp, vibrant visuals. The module operates in temperatures from -20°C to +70°C and supports a MIPI 2-lane interface for efficient data transmission. Its compact size (62.70*102.90*3.70 mm) and robust design make it ideal foroutdoor handheld devices, industrial controls, and vehicle displays, ensuring reliable performance in harsh environments.

Inquire Now

BackPrevious Next

Product Details

Size(inch)	4.0
Part Number.	LTK040BFBCT45-V0
Display Type	Transflective
Resolution	480* 800
Interface	MIPI 2 Lanes
Display colors	16.7M,full color
Luminance (cd/m²):	110
Viewing Direction	6, o’clock
Reflectivity	9.5%
Power Consumption	480 mW
Driver IC	ST7701S
Touch Screen	CTP
TP Structure	G+FF
TP Interface	IIC
Active Area (mm)	54.84 (H)x 86.4 (V)
LCM Module Size (mm)	62.70(H)x 102.90(V) x3.70 (T)
Operating Temperature	-20~+70℃
Storage temperature	-30~+80℃
