4 inch 400*960 UART TTL&232&485 touch screen display
This LTK040MNBUT24-V0 IPS LCD module has a resolution of 400*960 and a brightness of 410cd/m². The active area is 39.18*94.03mm and the overall size is 45.90*105.08*4.20mm. It is equipped with a capacitive touch screen (CTP) and can operate reliably in a temperature range of -20℃ to +70℃. It is designed for smart home applications to ensure clear, detailed visuals and stable performance in a variety of home environments.
- Product Details
|
Part Number. |
LTK040MNBUT24-V0 |
|
Resolution |
400*960 |
|
Display Mode |
IPS |
|
LCM A.A (mm) |
39.18*94.03 |
|
LCM O.D (mm) |
42.90*102.08*2.19 |
|
LCM Luminance |
480 |
|
Signal Input |
MIPI |
|
Signal Output |
UART TTL&232&485 |
|
PCB Outline |
130.00*80.00 |
|
Operating Temp |
-20~+70℃ |
|
Storage Temp |
-30~+80℃ |
|
Power |
5V/2A |
|
Touch Screen |
CTP |
|
TPM V.A (mm) |
39.78*94.63 |
|
TPM O.D (mm) |
45.90*105.08*4.20 |
|
TPM Luminance |
410 |
|
Flash |
1GB (support 128Mbit~2*1GB) |
