5 inch 800*480 TFT LCD Display with Touch and HDMI Board
The LTK050WVBHT17-V0 is a high-performance LCD module featuring an 800x480 resolution and advanced IPS technology for clear visuals and wide viewing angles. The module supports HDMI output for seamless connectivity, making it suitable for industrial control, smart devices, and automotive displays. Its robust design operates within a temperature range of -25°C to +70°C and supports both 3.3V and 5V power supplies, making it a reliable choice for demanding applications.
- Product Details
|
Model number |
LTK050WVBHT17-V0 |
|
Resolution |
800*480 |
|
Viewing Direction |
IPS |
|
LCM OD(mm) |
120.70*75080*2.80 |
|
LCM AA(mm) |
108.00*64.80 |
|
TPM V.A (mm) |
108.80*65.60 |
|
TPM O.D (mm) |
120.70*75.80*4.05 |
|
PCB Outline |
150.0*100.0*10.0 |
|
Signal Input |
RGB |
|
Signal Output |
HDMI |
|
LCM Brightness |
600 |
|
TPM Brightness |
510 |
| Touch Screen |
CTP |
| Power Supply |
3.3V/5V |
|
Operating Temperature |
-25~+70℃ |
|
Storage Temperature |
-30~+80℃ |
Get A Quote
If you are interested in our products and want to know more details. please leave a message here. we will reply you as soon as we can.
