5 inch 720*1280 TFT LCD touch display HDMI LCD controller board
This LTK050FTHHT29-V0 IPS LCD module has a high-resolution display of 720*1280 pixels and adopts capacitive touch screen (CTP) technology. It is designed for the smart industrial industry and can operate reliably in the temperature range of -20℃ to +70℃. It uses a 12V/3A power supply to ensure stable operation in various industrial environments.
- Product Details
|
Model number |
LTK050FTHHT29-V0 |
|
Resolution |
720*1280 |
|
Viewing Direction |
IPS |
|
LCM OD(mm) |
65.30*119.30*1.65 |
|
LCM AA(mm) |
62.10*110.40 |
|
TPM V.A (mm) |
62.70*111.00 |
|
TPM O.D (mm) |
70.65*151.60*3.25 |
|
PCB Outline |
51.0*37.0*3.0 |
|
Signal Input |
MIPI |
|
Signal Output |
HDMI |
|
LCM Brightness |
300 |
|
TPM Brightness |
260 |
| Touch Screen |
CTP |
| Power Supply |
12V/3A |
|
Operating Temperature |
-20~+70℃ |
|
Storage Temperature |
-30~+80℃ |
Get A Quote
If you are interested in our products and want to know more details. please leave a message here. we will reply you as soon as we can.
