High brightness 4 inch 480*480 Rugged Display
The LTK040WVHLM02-V0 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a home control system device. This model consists of a TFT LCD panel and a drive circuit. This TFT LCD has an active display area of 4 inches measured diagonally with a resolution of (480 horizontal x 480 vertical pixels). It has a brightness of up to 1100nits, an operating temperature of -20~+85℃, and the screen is rugged, waterproof and impact-resistant, making it a good choice for industrial scenarios.
- Product Details
| Model number | LTK040WVHLM02-V0 |
| Size(inch) | 4.0 |
| Resolution | 480*480 |
| Viewing Direction | IPS |
|
Interface |
MIPI |
|
Expandable interface |
SPI+RGB |
|
Luminance (cd/m²) |
1100 |
|
Active Area (mm) |
71.86*70.18 |
|
Outline Dimension (mm) |
77.36*80.28*2.84 |
| Driver IC | ST7701 |
|
Operating Temperature |
-20~+85℃ |
| Storage Temperature | -30~+85℃ |
