Leadtek 15 Inch 1024*768 TFT LCD UART Display

Welcome to Leadtek!Today we introduce a 15-inchTFT-LCD display module with aUART board. It has a resolution of 1024*768 and ahighbrightness of 750 cd/m². Its effective area is 304.13*228.10mm and supports LVDS interface. Its power is 12V/2A, Flash supports 128Mbit~2*1GB. High resolution can provide clear picture quality and a wide viewing angle range. At the same time it supports capacitive touch or resistive touch. The UART board based on Cortex-M4 MCU core, now let's take a look at the parameters of this UART board.

Application: Smart Medical

✅LCD Size:15 inch

✅Module number: LTK150FTFUT17-V0

✅Resolution:1024*768

✅Luminance (cd/m²): 750

✅Viewing Angle: IPS
✅Signal Input：LVDS
✅Signal Output：UART TTL&232&485
✅Power：12V/2A

✅Active Area (mm): 304.13(H)*228(V)

✅PCB+CTP+LCM Module Size (mm):367.30(H)x275.50(V)x17.10(T)

✅Touch Screen:CTP

✅Operating Temperature: -20~+70℃

✅Storage temperature: -30~+80℃

If you want to know more about this product, please leave a message or contact us.
